The USA Lab DLSB-30/40 is a powerful -40°C Chiller with a 30L Reservoir. This chiller is a true lab chiller than is ideal for applications involving vacuum systems, jacketed reactors, rotary evaporators, columns, solvent tanks, and even analytical instruments.


The USA Lab DLSB-30/40 chillers offer unbeatable performanceease of use and high reliability. These units keep quiet despite having a powerful pump allowing for constant flow rates to match the needs of demanding applications.

DLSB-30/40 SPECIFICATIONS

•Reservoir Capacity: 30L

•Reservoir Dimensions: 13.7″ x 13.7″

•Temperature Range: Room Temperature to -40°C / -40°F

Power Requirements: 220V
60Hz 30A 2500W Single Phase

•Refrigerating BTUs: 4,300BTU – 13,900BTU

•Circulating Pump Wattage: 100W

•Temperature Accuracy: +/- 0.5°C

•Pump Flow: 30L/Min

•Pump Pressure: 2.2bar

•Barb Size: 5/8″

•Refrigerant: R404

•Dimensions: 30.3″ x 25.5″ x 39.7″

•Weight: 180lbs

DLSB-30/40 PACKING LIST

USA Lab DLSB-30/40 Chiller

1 pc

5/8″ Insulated Tubing

11ft

5/8″ barbed Valve

1 pc

PTFE Sealing Tape

1 pc

-40°C Temperatures are tested under empty load.

This unit comes with a 30 day money-back guarantee and a 1 year parts and labor warranty
